Teknik Özellikler
| Güç kaynağı | 24VAC/DC (12…34 V AC 50Hz / 12…34 V DC), 2.0 VA |
|---|---|
| Boyutlar, dış (GxYxD) | 69x75x44 mm |
| Analogue output load impedance 0…10v | Min. 10 kΩ |
| Measuring range, temp | -30…70 °C |
| Sensor element, temperature | PT1000 |
| Measuring range, lux | 0…100000 lux |
| Output signal, lux | 0…10 V, corresponding to the selected measuring range |
| Accuracy, lux | ±10 % at °C |
| Koruma sınıfı | IP54 |
|---|---|
| Ortam nemi (yoğuşmasız) | 0…98 % RH |
| Depolama sıcaklığı | -30…70 °C |
| Montaj | Wall |
| Ağırlık, ambalaj dahil | 0.17 kg |
| Accuracy, temperature | ±0.3 K K |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Malzeme, gövde | Plastic PA6 |
| Colour, housing | RAL9010 |
