Spesifikasjoner
| Strømforsyning | 24VAC/DC (22…26 V AC 50Hz / 15…35 V DC), 2.0 VA |
|---|---|
| Dimensjoner, utvendig (BxHxD) | 100x85x30 mm |
| Visning | Ja |
| Measuring range, temp | 0…50 °C |
| Output temperature | 0-10 V |
| Sensor element, temperature 2 | PT1000 |
| Measuring range, humidity | 0…100 % RH |
| Output humidity | 0-10 V |
| Beskyttelsesklasse | IP30 |
|---|---|
| Omgivende luftfuktighet (ikke-kondenserende) | 10…90 % RH |
| Lagringstemperatur | -25…60 °C |
| Montering | Rom |
| Accuracy, temperature | ±0.3°C at 20 °C K |
| Nøyaktighet, temperatur 1 | ±0.4 °K @ 0…50 °C |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Materiale, hus | Polycarbonate (PC) |
| Colour, housing | Signal white RAL 9003 |
