Spezifikationen
| Stromversorgung | 24VAC/DC (12…34 V AC 50Hz / 12…34 V DC), 2.0 VA |
|---|---|
| Abmessungen, außen (BxHxT) | 69x75x44 mm |
| Analogue output load impedance 0…10v | Min. 10 kΩ |
| Measuring range, temp | -30…70 °C |
| Sensor element, temperature | PT1000 |
| Measuring range, lux | 0…100000 lux |
| Output signal, lux | 0…10 V, corresponding to the selected measuring range |
| Accuracy, lux | ±10 % at °C |
| Schutzklasse | IP54 |
|---|---|
| Umgebungsfeuchtigkeit (nicht kondensierend) | 0…98 % RH |
| Lagertemperatur | -30…70 °C |
| Montage | Wall |
| Gewicht, inkl. Verpackung | 0.17 kg |
| Accuracy, temperature | ±0.3 K K |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Material, Gehäuse | Plastic PA6 |
| Colour, housing | RAL9010 |
