Flow switch type: VK340M

Type: VK340M0SENNL09
Noryl PPO, SP-S7925
Brass pipe piece, G 1 1.2″ female thread, DN 40
Max. Medium temperature 100°C
Diameter : 40
Thread : G1 1/2
Switching point ranges ON / OFF ( l / min) :
ON : 27.0....33.5
OUT : 25.5...32.5
Max. Flow rate [l / min]: 300
Output potential-free contact
PVC sheathed cable 1500 mm

SIKA flow monitors are designed for minimum or maximum monitoring of the intended fluid flows. Custom designs should be discussed prior to ordering so that technical specifications can be adapted to requirements
Whether the flow switch is generated according to the requirements.

Brand	SIKA

Product Documents

Datasheet
