Trafag Pressure Transmitter with ship approval EPN-8298 / Range: 0 ...35000 PSIG

Trafag Druktransmitter met scheepskeur EPN-8298 / Range: 0 ...35000 PSIG - Image 2

Trafag Pressure Transmitter with ship approval EPN-8298 / Range: 0 ...35000 PSIG

Measuring range [bar]: 0...+35000 PSIG
Pressure connection: M18x1, 5 A HP
Sensor material: 1.4542
Ambient temp: -40...125 °C
Accuracy (type) FS, NLH (BSL): ±0.3%
Output: 4...20 mA
Power supply: 24 V DC
Cable 3 mtr.
Material number: 47510

Pressure range (Bar)	0 … 10, 0 … 100, 0 … 16, 0 … 25, 0 … 250, 0 … 4, 0 … 40, 0 … 400, 0 … 6, 0 … 60
Output	4 ... 20 mA
Overpressure max.	12, 120, 20, 200, 32, 50, 500, 8, 80, 800
Nutrition	9 ...32
Accuracy @25°c typ.	± 0.5
Brand	Trafag

Product Documents

Documents

Data sheet
