Automatic Charger HTC 2000

Function:

The HTC 2000 is one of the most advanced and intelligent diagnostic and test equipment for battery charging. The HTC 2000 works with state-of-the-art characteristic-controlled charging technology, ensuring optimal charging results
and optimized battery maintenance. The intelligent software constantly monitors all functions and regulates the ideal charging process
depending on the condition of the battery.

Equipped with

- I / U charging characteristic I-phase, U-phase
- Reverse pole and short-circuit protection by electronic control
- Trickle charge function - Battery test function
, defective battery detection
- For 12 V lead-acid batteries
- For 12 V Li- Ion starter batteries
- Charge current max. 2 A (automatic control)
- 9 status LED indicators

Technical specifications and features:

- Operating voltage: 220 - 240 V / AC (50 / 60Hz)
- Final charge voltage: 14.3 V
- Charging current: Max. 2 A
- Protection class (housing): IP65
- Operating temperature: -15 ° C to + 45 ° C
- Dimensions (L x W x H): 174 x 55 x 46 mm
- Weight: approx. 360 g
- Power cable length: approx. 1.50 m
- Charging cable length (incl. Accessories): approx. 1.90 m
- Fuse (charging cable): 10 A
- For 12 V lead-acid batteries
- For 12 V Li-Ion starter batteries
- Battery voltage: 12 V (6 cell lead-acid batteries)
- Battery capacity (recommended) : 1.2 Ah to 60 Ah
