Spécifications
| Alimentation électrique | 24VDC (11…30 V DC) |
|---|---|
| Dimensions, externes (WxHxD) | 75x266x75 mm |
| Media temp limits | 0…50 °C |
| Insertion length | 45…220 mm |
| Measuring range, temp | 0…50 °C |
| Output temperature | 4-20 mA |
| Measuring range, humidity | 0…100 % RH |
| Output humidity | 4-20 mA |
| Accuracy, humidity 1 | ± % RH @ 0…100 |
| Classe de protection | IP65 |
|---|---|
| Humidité ambiante (sans condensation) | 0…95 % RH |
| Température de stockage | -20...70 °C |
| Poids, emballage compris | 0.26 kg |
| Les médias | Air, non-combustible and non-aggressive gases |
| Précision, température 1 | ±1 °K @ 20…20 °C |
| Presse-étoupe | M16x1,5 |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Matériau, boîtier | Polycarbonate (PC) |
| Material, cover | Polycarbonate (PC) |
| Material, base | Polycarbonate (PC) |
