Spezifikationen
| Stromversorgung | 24VAC/DC (21…27 V AC 50/60Hz / 21…27 V DC), 5.0 VA |
|---|---|
| Abmessungen, außen (BxHxT) | 89x129x58 mm |
| Anzeige | Ja |
| Art der Anzeige | LED, three digits |
| Analogue output load impedance 0…10v | > 2 kΩ |
| Analogue output load impedance 4…20mA | < 500 Ω |
| Pressure, range sensor | 0…999 Pa |
| Accuracy, pressure sensor 1 | ±1 % full scale at 20 °C % |
| Damping (electronic) | 0…20 s |
| Schutzklasse | IP54 |
|---|---|
| Umgebungsfeuchtigkeit (nicht kondensierend) | 0...90 % RH |
| Lagertemperatur | -40…50 °C |
| Montage | Wall |
| Gewicht, inkl. Verpackung | 0.39 kg |
| Medien | Air and non-corrosive gases |
| Analogue outputs type (AO) | 0…10 V DC / 4…20 mA |
| Pressure, range sensor | 0…999 Pa |
| Kabelverschraubung | M16x1,5 |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Material, Gehäuse | Polycarbonate (PC) |
| Material sensor | Silicone rubber |
