Especificaciones
| Alimentación | 24VDC (11…30 V DC) |
|---|---|
| Dimensiones, externas (AnxAlxPr) | 75x266x75 mm |
| Media temp limits | 0…50 °C |
| Insertion length | 45…220 mm |
| Measuring range, temp | 0…50 °C |
| Output temperature | 4-20 mA |
| Measuring range, humidity | 0…100 % RH |
| Output humidity | 4-20 mA |
| Accuracy, humidity 1 | ± % RH @ 0…100 |
| Clase de protección | IP65 |
|---|---|
| Humedad ambiente (sin condensación) | 0…95 % RH |
| Temperatura de almacenamiento | -20...70 °C |
| Peso, embalaje incluido | 0.26 kg |
| Medios de comunicación | Air, non-combustible and non-aggressive gases |
| Precisión, temperatura 1 | ±1 °K @ 20…20 °C |
| Prensaestopas | M16x1,5 |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Material, carcasa | Polycarbonate (PC) |
| Material, cover | Polycarbonate (PC) |
| Material, base | Polycarbonate (PC) |
