Name: CTHRA
SKU: CTHRA
Availability: InStock

Especificaciones

Specificaties voor CTHRA
Alimentación	24VAC/DC (22…26 V AC 50Hz / 15…35 V DC), 2.5 VA
Dimensiones, externas (AnxAlxPr)	100x85x30 mm
Time constant	90 s
Measuring range, temp	0…50 °C
Output temperature	0-10 V
Measuring range, humidity	10…90 % RH
Output humidity	0-10 V
Measuring range, gas in air	0…2000 ppm
Output signal, gas in air	0-10 V
Accuracy, gas in air	< ± (50 ppm + 2 % of the measured value)
Long term stability	Typically 20 ppm / year
Warm-up time	< 5 min
Temperature dependance	Typically 5 ppm / K

Specificaties voor CO₂, temperature and humidity transmitter, room mounting
Clase de protección	IP30
Humedad ambiente (sin condensación)	10…90 % RH
Temperatura de almacenamiento	-25…60 °C
Montaje	Habitación
Accuracy, temperature	±0.3°C at 20 °C K
Terminal type	Screw Terminal
Terminal wire size	1.5 mm²
Material, carcasa	Polycarbonate (PC)
Colour, housing	Signal white RAL 9003

CTHRA
