Müller Magnetic Surface Temperature Sensor HART NX

Type: 1500-00273
Ingang: Pt100 Sensor
Klasse A
Procesaansluiting: magnetische basis
Grenscontact: 2 x PNP, 30 V, 200 mA
Configuratie: fabrieksinstelling,
Bereik: +10 … + 80 ° C
Uitgang: 4-20 mA
Display: 4 cijfers, 7 segmenten
Voeding: HART-stroomlus 12-40 VDC

technical features

Input: RTD Pt100 (maximum range -50…+200 °C)
Output: 4…20 mA current loop HART (2-wire)
Voltage supply: out of current loop (12…40 VDC)
Accuracy: see technical details
Process connection: clamping magnet
Electrical connection: several plugs
Temperature range: -20…+80 °C (ambient)
Limit value contacts: 2 electronically (NPN / PNP)
Adjustment: keys / software
Material: stainless steel 1.5471 (medium contact)
Protection: at least IP65

Merk	Müller IE
