Gauge Cocks with Gland
AS-Schneider Gauge Cocks are basically designed, manufactured and tested according to DIN 16261, DIN 16262 and DIN 16263. According to above standards the cocks are applicable for a max. allowable (Working) Pressure (PS) of 6 – 16 bar (87 - 232 psi) and a max. allowable Temperature (TS) of 50°C (122°F) for liquids, gas or vapors. Originally the AS-Schneider Gauge Cocks were designed for a max. allowable (Working) Pressure (PS) of 25 bar (363 psi) for the G 1/2 models. We kept this pressure class for this kind of gauge cocks, see below Ordering Information.
The Gland Type is a special design and not mentioned in above DIN standards.
Operating Positions are marked on top of the plug.
Productvariaties
| Inlet | Outlet | Material | PN | L | H | Hex | Test Connection | References | Part Number 1 | Part Number 2 | Offerte |
|---|---|---|---|---|---|---|---|---|---|---|---|
| G 1/2 Female | G 1/2 Female | Brass | 25 | 70 | 65 | 27 | N003.09.000 | N00309000 | |||
| G 1/2 Female | G 1/2 Female | Brass | 25 | 70 | 65 | 27 | With Vent | N003.09.000.02 | N0030900002 | ||
| G 1/2 Male | G 1/2 Female | Brass | 25 | 70 | 65 | 27 | Test Flange 60 x 25 x10 | N003.09.070.01 | N0030907001 | ||
| G 1/2 Male | G 1/2 Female | Brass | 25 | 70 | 65 | 27 | Test Flange 60 x 25 x10 | N003.09.070.01 | N0030907001 | ||
| G 1/2 Male | G 1/2 Female | Brass | 25 | 77 | 65 | 27 | N003.10.000 | N00310000 | |||
| G 1/2 Male | G 1/2 Female | Brass | 25 | 77 | 65 | 27 | With Vent | N003.10.000.02 | N0031000002 |
