• Ship building applications, on-offshore, military
  Pressure transmitters - Pressure switches - Thermostats - Fuel consumption sensors - Tank level instruments - Temperature sensors
• High voltage technology, power plants, water treatment
  SF6 sensors-switches - HART, profibus sensors - Pneumatic time relays - Actuators, valves - Flow measurement - Pressure sensors, switches
• Ex - applications
  Pressure transmitters - Ex modules/sensors - Pressure switches - Thermostats, tracing - Turbine flow sensors - Valve-linear actuators
• Heating & Ventilation
  Humidity, smoke sensors - HART, profibus sensors - Valves, actuators - Thermostats, frost detection - Temperature sensors - Displays-indicators
• Industrie, chemistry, pharmacy, test benches
  Pressure sensors - HART, profibus sensors - Flow sensors - Indicators-displays - Level instruments - Temperature sensors
• Industry & Hydraulics
  Pressure transmitters - Monitoring instruments - Inclination sensors - Level measurement - Force sensors, load cells - Temperature sensors
• Ship building applications, on-offshore, military
  Pressure transmitters - Pressure switches - Thermostats - Fuel consumption sensors - Tank level instruments - Temperature sensors
• High voltage technology, power plants, water treatment
  SF6 sensors-switches - HART, profibus sensors - Pneumatic time relays - Actuators, valves - Flow measurement - Pressure sensors, switches
• Ex - applications
  Pressure transmitters - Ex modules/sensors - Pressure switches - Thermostats, tracing - Turbine flow sensors - Valve-linear actuators
• Industry & Hydraulics
  Pressure transmitters - Monitoring instruments - Inclination sensors - Level measurement - Force sensors, load cells - Temperature sensors
• Heating & Ventilation
  Humidity, smoke sensors - HART, profibus sensors - Valves, actuators - Thermostats, frost detection - Temperature sensors - Displays-indicators
• Industrie, chemistry, pharmacy, test benches
  Pressure sensors - HART, profibus sensors - Flow sensors - Indicators-displays - Level instruments - Temperature sensors
• High voltage technology, power plants, water treatment
  SF6 sensors-switches - HART, profibus sensors - Pneumatic time relays - Actuators, valves - Flow measurement - Pressure sensors, switches
• Industry & Hydraulics
  Pressure transmitters - Monitoring instruments - Inclination sensors - Level measurement - Force sensors, load cells - Temperature sensors
• shipbuilding applications
• railway
• automotive & hydraulics
• high voltage technology
• industry
• ex - applications
• heating & ventilation

Marktechnical, sensors and controls

Marktechnical B.V. an advanced trading company which delivers high quality measuring and control instruments for industrial and shipbuilding applications. We have Trafag sensors and switches for (mobile)hydraulics, cooling & heating installations, steering gears, tank and monitoring systems, automotive applications, hazardous areas and much more.

Do you need to control or measure pressure, temperature, level, force, angle, flow, humidity, time or do you need a specific custom-made product; we have the solution!

Products

• Pressure
  • Switches
  • Transmitters
• Temperature
  • Switches
  • Sensors
  • Transmitters
• Level
• Digital indicators
• Flow
• Radio transmission
• Force
• Agastat relays
• Explosion proof
  • Pressure
  • Temperature
• Can-open
• Dataloggers
• Others

Applications

• Shipbuilding
• Railways
• Industry & Hydraulics
• Heating & Ventilation
• Airco & Refrigeration
• Ex - applications
• High voltage techn.

Contact

Product news

ECE/ECT: Reliable industrial pressure transmitter with interesting cost-performance ratio
	The new generation of pressure transmitters for industrial applications is available. The redevelopment is based on media resistant pressure sensors with thick film on ceramic technology. With its optimized cost-performance ratio it covers much more applications than the forerunner model. The ASIC (Application Specific Integrated Circuit) chip is a significant part of this transmitter. Years of experience in designing electronic pressure transmitters are integrated. According to the application can chose between two different housing material qualities. Type `ECE` allows further savings in costs. Housing in brass: Type ‚`ECE` Housing in stainless steel: Type ‚`ECT` Download datasheet

Turbine flow meters (HM)
	Flow measurement of fuels, light fuel oil, thermal oil, solvents, tap and demineralised water. Special turbine meters for refrigerants. Measuring ranges from 0.03 up to 48,000 l/min. Typcal viscosity range from 0.5 - 100 mm²/s

Mobile wheel-/axle load platform scales
	These scales with excellent price-performance ratio have the advantage of being easily movable, quickly and easily implementable and almost everywhere to be operational.These mobile Floor Scales operate on all fixed and flat surfaces, after uncomplicated setup operation by one-person. The weights are determinated precisely and exactly where they are needed. Download datasheet

Modular (differential) pressure transmitter
	Suitable to measure differential pressure. Areas of use: chemical,process industry,on-offshore Pressure: differential Ranges from -75...+75 mbar up to -420...+420 bar Output: 4...20 mA HART Supply voltage: current loop, 15...30VDC Accuracy: 0,1%, 0,075%, 0,2% of span Degree of protection: IP65 Medium contact parts stainless steel 1.4435 Process connection 1/4-18NPT Display with programming keys Turn down up to 100:1 Download datasheet

Small in size (19 mm) - big in performance
	Industrial pressure transmitter NAT Hydraulic pressure transmitter NAH Engine pressure transmitter NAE Range: 0... up to +600 bar Output: 4-20 mA, 0-10 V DC, Can-open etc. Supply: 24 V DC Accuracy: 0,2% FS Housing: Stainless Steel Sensor: 1.4542 (ASIC technologie) Weight: appr. 50 g Click here for more information

Valve block from Trafag
	The DIAGNOSTIC VALVE BLOCK (DVB) represents an indispensable, highly variable accessory for the diagnostics, controlling or exchange of pressure measuring instruments in hydraulic and pneumatic applications. The well thought through DVB lends itself to all applications but in particular is most suitable wherever versatility is required and operation cannot be interrupted. Adjustments to the diagnostic valve block in depressurised condition do not require an interruption of operation. Material Al abrasion resistant Operating pressure 0...180 bar Operating temperature -20... +120 Grd.C Protection IP67 Download datasheet
